Congratulations to this customer from Belize who received the DXTECH DX-125T/3200mm ESA 630 Electro Hydraulic Press Brake Machine.
DXTECH has been deeply involved in the laser product industry for more than ten years and has rich export experience. DXTECH’s main fiber laser cutting machine business has high cutting efficiency and good cutting quality. Widely used in sheet metal processing, automobile manufacturing, mold manufacturing, furniture manufacturing and other industries. In 2013, DXTECH launched a series of hydraulic bending machine products to meet the different production needs of customers.
This customer is engaged in the mold industry and not only needs a laser cutting machine to process large-area metal sheets, but also needs a bending machine to perform auxiliary work. After various comparisons between hydraulic press brakes and torsion axis press brakes, the customer finally chose this 125T/3200mm ESA 630 Electro Hydraulic Press Brake Machine. This machine is our most popular model. On the basis of the original 125T/2500mm, the length of the workbench has been increased. It is a bending machine designed by us through research on frame bending.
Recently, the pre-shipment debugging, inspection and packaging process of the DXTECH-125T/3200mm hydraulic bending machine has been successfully completed. The customer successfully received the machine and put it into production. Our engineering team conducts equipment commissioning and quality inspection with a high degree of professionalism, ensuring that every detail meets the highest standards.
Advantages of 125T/3200mm Press brake machine
1.Electrical Parts
- The equipment adopts Schneider components imported from France, which are famous for their stability, durability, and long service life.
- The machine is equipped with Eston’s original self-adaptive electrical box assembly, which has strong anti-interference ability and stable electrical performance.
2. Optimized Base Frame: Very stiff and stable base frame
- Deformation simulation made by CAE
- Stress points analysis
- Usage of high-tech boring machines for extreme precision parts.
3. S630 Numerical Control System
- The special CNC system developed by the Italian ESA company has economical and easy-to-use CNC high-level performance.
- Efficient algorithms optimize the bending cycle, reduce the setup time of work steps, and increase the overall efficiency of the bending process, especially in batch-processing scenarios.
- Strong anti-interference ability, high reliability, and accuracy. Can accommodate 2D and 3D graphics editing.
4. German OKDO IPM series
- With axial and radial pressure compensation design, it can maintain high volumetric efficiency even at low speed and low viscosity.
- Ultra-low noise, using high-strength cast iron and unique internal muffler design, making the noise even lower.
- Extremely low flow and pressure pulsation, and can maintain stable flow and pressure output even at low speeds.
TECHNICAL PARAMETERS
| 1 | Model | 125T/3200mm |
| 2 | CNC System | ESA S630 |
| 3 | Nominal Force | 1250kN |
| 4 | Table Length | 3200mm |
| 5 | Distance Between Columns | 1560mm |
| 6 | Throat Depth | 350mm |
| 7 | Slider Stroke | 200mm |
| 8 | Opening Height | 460mm |
| 9 | Oil Pump | 16F |
| 10 | Main Motor Power | 7.5KW |
| 11 | Control Accuracy | ±0.01mm |
| 12 | Number Of Control Axes | 3 Axes (Y1, Y2) |
| 13 | Electrical Components | Schneider |
| 14 | Ball Screw | TBI |
| 15 | Back Gauge Guide Rail | HIWIN |
Other press brake options
$7,500.00 – $13,000.00
$7,500.00 – $13,000.00
$7,500.00 – $13,000.00
$7,500.00 – $13,000.00
$7,500.00 – $13,000.00
$7,500.00 – $13,000.00
$7,500.00 – $13,000.00
WARRANTY & GUARANTEE
DXTECH Product Warranty Terms:
1. Warranty Period: DXTECH warrants its products and components to be free from defects in material or workmanship for two years after the original date of receipt.
2. Service During Warranty: Under normal use and maintenance, we will replace damaged parts free of charge (laser source is only repaired, not replaced).
3. Service Out of Warranty: Even outside the warranty period, you can still get spare parts at cost price. Our engineers will provide you with the best technical service within 24 hours.
Actively respond to customer needs
- Professional after-sales service team provides you with 24-hour multilingual online and offline services.
- Free installation guidance training, equipment maintenance.
- DXTECH can provide you with professional workshop planning and future equipment upgrade solutions.
DXTECH-125T/3200mm ESA 630 Electro Hydraulic Press Brake Machine for Sale in Belize
DXTECH is a comprehensive enterprise integrating R&D, production and sales. With more than 12 years of experience in the laser industry. The main products include fiber laser cutting machine, laser engraving machine and laser marking machine, which can realize your metal or non-metal processing. The products are exported to more than 180 countries and regions including Europe and America. We are committed to providing integrated laser applications to users all over the world.
If you are interested in this machine, please contact us:
Cutting capacity 0.5mm-25mm, bending 1mm-10mm
